BURNED WATER HEATER OUTLET

Burned Water Heater Outlet

I just received a message in my Messenger from a known friend. She is worried about the outlet of her single point, wall mounted Water Heater.that just got burned. She called an electrician to check the problem and the electrician suggested replacing the burnt outlet with a circuit breaker.,

What is the problem?

Water Heater consumes a higher load compared to other common appliances or utility equipments in our home. Because of this, a higher rating of wires, outlet devices, and overload protective devices or circuit breakers are required enough to carry the current and ensure safety upon its use. In this case, I suspect that the outlet device used is underrated. It won't burn or melt instantly because the time of use for the water heater is intermittent. It takes time to for the element plate to deteriorate until it can no longer handle the heat produced in it.

It is also possible that there is loose contact between the terminal and the inserted wire. It may also be possible that the strand of wires was lessened just to be able to insert the wire easily, which is not permitted. Correct installation and good workmanship are very important in electrical installations. Safety of an electrical system relies on this, in addition to proper material specifications.

Outlet devices to be used for water heaters must have a rating capable of carrying the current drawn by the appliance.load. Using an underrated device will surely cause a problem anytime and the worst thing is that it can be a possible source of fire.

HOW TO DETERMINE THE NUMBER OF LIGHTING FIXTURES IN ONE CIRCUIT

How To Determine The Number Of Lighting Fixtures In One Circuit

Many asked, what is the maximum number of lighting outlets for a 15A or 20A circuit breaker, and what is the maximum number of convenience outlets in a 20A circuit breaker? I often hear these questions from friends in the construction field repairing designs for projects. Electrical Plan is one of the design plans required in acquiring a building permit in the Philippines before execution by the owner or its contractor. Some limit the number of lightings in one circuit to 12, and 8 for convenience outlet. Ideally, this is a good practice, but are these the maximum allowed numbers? I'll show you below how to determine the maximum ideal number of lighting fixtures in one circuit.

As a reference for a 15A circuit breaker, we use 2.0mm square stranded wire or #12 AWG for the circuit.

Given Parameters:

Nominal Voltage: 230Volts

Circuit Breaker rating @ 80% Safety Factor: 12Amperes

Total Computed Load in Watts: ____, to be determined

Formula:

P = I x V

Where,

P is the total computed power in Watts(W)

I is the total current available in Amperes(A), and

V is the given voltage

P(Watts)= 12A x 230V

                = 2,760Watts

So, the maximum allowable wattage for the lighting circuit is 2,760watts. Assuming we have light bulbs with 50Watt ratings, the total number of lighting fixtures for this circuit is,

No. of Lighting Fixtures= 2,760W/15W, which is 55.

Now we know the maximum number of lighting fixtures for this circuit is 55 sets. Where can this be applied? I have applied this in a function room and a hallway of a hotel project, also in residential, but the number of fixtures reached only to about 30 sets. The number of lighting fixtures depends on their application and the zone location. For example, you have 15 lighting fixtures for the kitchen, dining, and living area, 10 in combined bedrooms, and 25 at the exterior is good for each lighting circuit. In reality, we don't really need to reach that 55-sets mark, but it is not economical to limit the number of lightings in a circuit due to not knowing the allowable number of sets. The advantage of the zoning arrangement of lighting circuits is to lessen the affected area when trouble occurs to a specific circuit

HOW TO DETERMINE THE SIZE OF WIRES FOR SPECIAL PURPOSE OUTLETS

How To Determine The Size Of Wires For Special Purpose Outlets

Here is another concern I frequently hear from an online group of electricians. I understand that some of them are new, and others are in the group to learn. In most cases, special-purpose outlets are those that consist of loads like the water heater, electric ranges, refrigerators, and home appliances that have higher loads and are usually fixed in their locations.

In this case, we only cover non-complicated and individual appliances for the sake of first-hand ideas or knowledge in this regard. The very first thing to put in mind is that the size of wire or cable to be used must be able to carry the current drawn by the utilization equipment or load. The circuit breaker must also coincide with the wire or cable rating to ensure safety.

The best reference in determining the size of wire or cable, including the size of the circuit breaker protection of the unit is the equipment's nameplate rating usually placed at the back of the equipment's body or enclosure. Usually, what is given are the voltage, current, wattage, frequency rating, and the phasing. Knowing the wattage or current rating, you are given the idea and you can come up with the proper size of wire and its circuit breaker protection.

Fig. 1. Mini Ref



Fig. 1 Photo shows a sample specification rating at the upper right corner of a mini-refrigerator.

 Fig. 2. Mini Ref



Fig. 2 Enlarged photo of the sample specification rating at the upper right corner of a mini-refrigerator.

Only, you should always remember that the current ampacity rating of the wire to be used shall, in no way, be lesser than the current rating of the equipment serve, There are also other technical considerations that have to be considered when coming up with the proper sizing of circuit wires and circuit breaker protection. Continuous loads, motors loads, the distance of the load or equipment served, and others. I will be discussing them next as I go on with my blog.
